Epoxy Potting Compound
Original price was: ₹650.00.₹365.00Current price is: ₹365.00.1 Kg Set
- PCBs & Sensors: Protects sensitive electronic circuits from moisture, dust, and vibration, ensuring stable performance and extended lifespan.
- Automotive Electronics: Encapsulates control units, ignition modules, and sensors to withstand heat, oil, and mechanical stress in harsh environments.
- Transformers & Coils: Provides excellent electrical insulation and thermal stability, improving efficiency and preventing short circuits.
- LED Systems: Used in LED drivers and modules to enhance heat dissipation and ensure long-term performance in outdoor applications.
- Power & Energy Equipment: Protects components like battery packs and solar inverters from electrical leakage and thermal degradation.
- Consumer Electronics: Used in chargers, adapters, and appliances to prevent moisture ingress and improve product safety and reliability.
50 in stock
PRODUCT DESCRIPTION
| Brand Name | EPOMAX® |
| Brand Ownership | Owned by JAIPRABHA POLYMER TECHNOLOGIES |
| Nature of Business | Manufacturer of modified epoxy resin, hardener & polyurethane chemicals |
The epoxy potting compound is a protective material, typically made from resin and hardener and polyurethane, or silicone, used to encapsulate electronic components. In this process, the entire circuit or assembly such as a PCB, transformer, or sensor is completely covered and sealed within the compound. This creates a durable protective shell that safeguards the components from moisture, vibration, dust, heat, and other environmental factors, ensuring long-term reliability and electrical insulation.
Epoxy potting compound is a two-part resin system used to fully encapsulate electronic components so they are sealed and protected from damage once cured.
Straight facts — what it does:
- Locks electronic parts in place so nothing moves or vibrates.
- Blocks moisture, dust, chemicals, and corrosion.
- Insulates against heat and electricity.
- Extends product life by shielding the circuit from harsh environments.
What epoxy potting protects against
- Vibration and shock
- Moisture and humidity
- Water ingress and salt spray
- Chemical attack (oil, fuel, solvents)
- High voltage breakdown
- Dust and corrosive atmosphere
- Short circuits & tracking
Common problems if wrong grade is used
- Overheating → PCB failure
- Cracking due to thermal stress
- Moisture ingress over time
- Incomplete curing → sticky surface
- Burning or charring under high temperature
TECHNICAL SPECIFICATION
Product Name Epoxy Hard Potting Compound
Brand EPOMAX ®
Packaging Size 10 Kg, (Resin 8.00 Kg + Hardener 2.00 Kg)
Features PART A:- Clear Resin, Excellent Protection, Strong Adhesion, Electrical Insulation, Thermal Stability, Chemical Resistance, Mechanical Strength, Vibration and Impact Resistance, Corrosion Prevention, Long-Term Durability, Versatile Applications
Features PART B:- Brown Hardener, Fast-curing, Chemical-resistant, Thermally stable, Insulating, Durable, Versatile
Application – Epoxy potting compounds protect and insulate sensitive components across various applications. They shield PCBs, sensors, and control units from moisture, dust, vibration, heat, and chemicals, ensuring long-term reliability. Widely used in automotive systems, transformers, LEDs, and power devices like battery packs and solar inverters, they provide excellent electrical insulation, thermal stability, and durability, enhancing overall performance and lifespan.
The epoxy hardener is essential in potting compounds as it triggers the curing and crosslinking of the resin, defining the final material’s strength, thermal stability, and curing time. It enhances chemical resistance, adhesion, durability, ensuring the compound forms a solid, protective layer with excellent electrical insulation and moisture protection for demanding electronic and industrial applications.
|
Resin Color |
Black / Grey / Red/ Blue / Brown |
|
Hardener Color |
Brown |
|
Mixing ratio |
Call us – we have 2 difference ratios |
|
Gel Time |
20 To 25 minutes |
|
Curing Time |
8 TO 10 Hours |
|
Form |
Liquid |
|
Shelf Life |
6 months from the date of manufacturing |
|
Packaging Type |
Part A: HDPE bucket 8 + Part B: 2 Kg, HDPE Bucket & Can |
|
Manufacturer |
Jaiprabha Polymer Technologies |
|
Certification |
ISO 9001:2015 | ISO 14001:2015 | ROHS | MSME |
|
TrustSEAL Seller at B2B Portal |
IndiaMART, Exporters India, JustDail, Dail4Trade |
|
Online Social Media Portal |
Industry Buying, Flipkart, Shopsy, Meesho, SnapDeal, JioMart. |
|
Country of Origin |
Made in India |
